AISI 4140 Scm440 42CrMo4 1.7225 QT Hot Rolled Forged Steel Alloy Round Bar OD 290mm

Name: AISI 4140 Scm440 42CrMo4 17225 QT Hot Rolled Forged Steel Alloy Round Bar OD 290mm
Brand: TSING SHAN
Price: 0.65 USD

China AISI 4140 Scm440 42CrMo4 1.7225 QT Hot Rolled Forged Steel Alloy Round Bar OD 290mm wholesale

Brand Name : TSING SHAN

Model Number : AISI 4140

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : 0.65-0.95 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Export Packing

Tech : Hot rolled

Transport Package : Export Standard Package/as Request

Custom Made : Yes

Physical Properties : Specific Gravity 7.85

Dimensions : 16-400mm

Mechanical Properties : as Standard

Model No : 40cr JIS SCr440 DIN 1.7035

Technics : Hot Rolled

Machinability : Good

Secondary Or Not : Non-secondary

Service : Cutting

Ends : Beveled/plain

Hs Code : 7312000

Welding : conventional methods

Contact Now

AISI 4140 Scm440 42CrMo4 1.7225 QT Hot Rolled Forged Steel Alloy Round Bar OD 260mm

1: AISI 4140 steel introduction
AISI 4140 is defined as a low alloy steel which has 1% Cr-Mo as strengthening alloy elements.Compared with AISI 4130, it has a higher carbon content with good balance of strength, toughness ,abrasion and impact resistance and heat treatment capabilities,but poor in weldability characteristics.AISI 4140 is generally supplied in quenched and tempered condition with hardness 28-32HRC

2: AISI 4140 Steel equivalent

Country	China	Japan	Germany	USA	British
Standard	GB/T 3077	JIS G4105	DIN (W-Nr.) EN 10250	AISI/ASTM ASTM A29	BS 970
Grade	42CrMo	SCM440	42crmo4/1.7225	4140	EN19/709M40

3: AISI 4140 steel chemical composition

Grade	C	Si	Mn	P	S	Cr	Mo	Ni
42CrMo	0.38-0.45	0.17-0.37	0.5-0.80	≤0.035	≤0.035	0.9-1.2	0.15-0.25	-
SCM440	0.38-0.43	0.15-0.35	0.6-0.85	≤0.035	≤0.04	0.9-1.2	0.15-0.30	-
42crmo4/1.7225	0.38-0.45	≤ 0.4	0.6-0.9	≤0.025	≤0.035	0.9-1.2	0.15-0.30	-
4140	0.38-0.43	0.15-0.35	0.75-1.00	≤0.035	≤0.04	0.8-1.1	0.15-0.25	-
EN19/709M40	0.35-0.45	0.15-0.35	0.5-0.80	≤0.035	≤0.035	0.9-1.5	0.2-0.40	-

4: AISI 4140 steel mechanical properties(for guidance only)

Grade	Tensile strength σb(MPa)	Yield strength σs (MPa)	Elongation δ5 (%)	Reduction ψ (%)	Impact Value Akv (J)	Hardness
4140	≥1080	≥930	≥12	≥45	≥63	28-32HRC

5: AISI 4140 steel overviews

Size	Round	Dia 6-1200mm
	Plate/Flat/Block	Thickness 6mm-500mm
		Width 20mm-1000mm
Heat treatment	Normalized ; Annealed ; Quenched ; Tempered
Surface condition	Black; Peeled; Polished; Machined; Grinded; Turned; Milled
Delivery condition	Forged; Hot rolled; Cold drawn
Test	Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment terms	T/T;L/C;/Money gram/ Paypal
Trade terms	FOB; CIF; C&F; etc..
Delivery time	30-45 days
Application	AISI 4140 steel finds many applications as forgings for the aerospace,oil and gas,automotive, agricultural and defense industries etc. Typical applications for 4140 steel uses include:forged gears,spindles,fixtures,jigs,collars,Axles,conveyor parts,crow bars,logging parts,shafts,sprockets,studs,pinions,pump shafts, rams, and ring gears etc

6: Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.

AISI 4140 Scm440 42CrMo4 1.7225 QT Hot Rolled Forged Steel Alloy Round Bar OD 290mm
